Setting Up A Cloud Server - Part One!

This is the first entry to our very own development blog.

Over the next few months we will be focusing mainly upon iOS development as we begin giving life to a few game ideas we have.

But first, let's take a look at how this website was created!

In part one - we will talk about setting up a cloud server.

Server

We created a new server instance using Rackspace's brilliant cloud hosting facility - opting for a 256mb RAM, 10GB HDD Ubuntu 10.04 Lucid Lynx starter image. At a cost of $0.015 per hour - and a GBP exchange rate of about $1.66 to £1 - it is fairly cheap, oh and some small bandwidth costs too - check out their offering.

With such as small amount of ram, and the primary use of this 'cloud slice' being the hosting of this blog, we didn't want to install the full blown wordpress or [insert other blog cms] software, but rather create our own lightweight blog front and backend - something that has just the right amount of features. Not only that, but we can also take pride that as an application development company, we created our own software for our website!

When you sign up to rackspace and create your first server instance you are given and later emailed the IP for the server and root passwords.

If you want to you a domain name to access the server, you have the ability to edit DNS settings from within your control panel. At time of writing, all you need to do with your domain provider is change the nameservers for the domain to the following:


dns1.stabletransit.com

dns2.stabletransit.com

Then in rackspace go to cloud servers overview screen and from the dns tab for each domain

  • add an A record - name: domain.com content: ip address ttl: 300 type: A
  • (if mailserver) add an MX record - name: domain.com content: domain.com priority: first record 10, next 20 etc ttl: 300 type: MX
  • add a CNAME record - name: www.domain.com content: domain.com ttl: 300 type: CNAME
  • for any intended subdomains add a CNAME record for them too (cname as they are on same ip, otherwise A record)
  • set the reverse dns as the hostname of the server ---> eg. mainserver.domain.com. (dot at end too)
Server Software

The linux based server had the normal configuration done as per usual barebones installations:

  • Changing root password and create a new user

    SSH into the cloud server instance, logging in as root - we are using an Apple computer so can use the terminal application - on windows you can use a program such as putty.

    # ssh root@99.99.99.99

    As you are now logged in as root, using the below command you can change the password from the one Rackspace gave you when creating the server instance.

    # passwd

    Still logged in as root, you create a new user (the user you will work as). You will be prompted by the operating system for a new password for this user as well as other information such as name and contact details.

    You should avoid logging in as root, in order to prevent opportunities where the cloud server could be compromised.

    # adduser mynewusername

    Using the newly created user 'mynewusername' for all tasks will require you to have sudo (Super User) privileges - this means that this user could, with a password, have full root access.

    # usermod -a -G sudo mynewusername

    # visudo

    The previous command will bring up the configuration file for the sudo program. Toward the bottom of the file you will see the following:

      # Uncomment to allow members of group sudo to not need a password
       # (Note that later entries override this, so you might need to move
       # it further down)
       # %sudo ALL=NOPASSWD: ALL


    Add the following under it:

       ## Allows people in group to run all commands
       %sudo  ALL=(ALL)       ALL


    Save the file by pressing CTRL-X, Y and then ENTER - this allows the sudo group to have full sudo (Super User) privileges, a group of which 'mynewusername' is now a member of.

    From now on you can login as follows:

       # ssh mynewusername@99.99.99.99


    Once logged in, by type sudo su and pressing Enter will prompt you for your password - after which you have root/super user privileges.

  • Basic Server Security

    Linux distributions such as Ubuntu can use package managers to install/upgrade sofware - packages such as 'apt-get' and 'aptitude'.

    Firstly update the sources repository for these by editing the follwing file:

    # sudo nano /etc/apt/sources.list

    Add the following lines to it:

    deb http://ppa.launchpad.net/brianmercer/php/ubuntu lucid main

    deb-src http://ppa.launchpad.net/brianmercer/php/ubuntu lucid main

    Now run the following command to add the signed key for these sources:

    # sudo apt-key adv --keyserver keyserver.ubuntu.com --recv-keys 8D0DC64F

    You can now update the package manager caches:

    # apt-get update
    # apt-get upgrade
    # aptitude update
    # aptitude upgrade


    When upgrading you will be prompted to confirm, enter Y and press ENTER.

    Firewalls

    The Linux firewall system is controlled by the configuration of iptables application. This can be viewed by running the following command:

    # iptables -L

    This would provide the following output:

    Chain INPUT (policy ACCEPT)
    target     prot opt source               destination
    ACCEPT     all  --  anywhere             anywhere            state RELATED,ESTABLISHED
    ACCEPT     tcp  --  anywhere             anywhere            tcp dpt:ssh

    Chain FORWARD (policy ACCEPT)
    target     prot opt source               destination

    Chain OUTPUT (policy ACCEPT)
    target     prot opt source               destination


    You now need to add additional rules to the iptables in order to control the flow in and out of the cloud server instance. Start by adding the following rules line by line:

    Allowing established connections:

    # iptables -A INPUT -m state --state ESTABLISHED,RELATED -j ACCEPT

    Allowing SSH traffic:

    # iptables -A INPUT -p tcp --dport ssh -j ACCEPT

    Allowing HTTP traffic:

    # iptables -A INPUT -p tcp --dport 80 -j ACCEPT

    Allowing FTP traffic:

    # iptables -A INPUT -p tcp --dport 20 -j ACCEPT

    Allowing FTP traffic:

    # iptables -A INPUT -p tcp --dport 21 -j ACCEPT

    Allowing SMTP traffic:

    # iptables -A INPUT -p tcp --dport 25 -j ACCEPT

    Drop remaining traffic:

    # iptables -A INPUT -j DROP

    Allowing loopback traffic:

    # iptables -I INPUT 1 -i lo -j ACCEPT

    Now with all these rules input, you can view the tables again by typing:

    # iptbles -L -v

    Save the rules by following these commands:

    # iptables-save > /etc/iptables.rules


    Make sure the iptables.rules is run at every boot up:

    # nano /etc/network/if-pre-up.d/iptaload


    The text editor will load, paste in the following:

    #!/bin/sh
    iptables-restore < /etc/iptables.rules
    exit 0


    Save the file by pressing CTRL-X, then Y and Enter.

    You will also need to create a script to run if the server is shutdown:

    # nano /etc/network/if-post-down.d/iptasave

    In the text editor, paste the following:

    #!/bin/sh
    if [ -f /etc/iptables.downrules ]; then
       iptables-restore < /etc/iptables.downrules
    fi
    iptables-save -c > /etc/iptables.save
    exit 0


    Save the file.

    Set permissions on these two scripts to make them executable:

    # chmod +x /etc/network/if-post-down.d/iptasave
    # chmod +x /etc/network/if-pre-up.d/iptaload


Now the basic server is set up, you have created users, allowed super user privileges using the sudo command, updated application repositories and set up firewalls.

In the next article, we will do a run through on installing and setting up FTP, setting time zones and installing postfix to enable outgoing email from this server.
